1.Panels, buttons made of high quality stainless steel, has a strong anti-destructive
2.Font button surface and pattern can be customized according to customer requirements
3.PCB double sided, metal dome lines, access to reliable
4.Key word laser engraving, etching, oil filled, high strength paint
5.4x4 keyboard matrix scanning,10 numeric keys,6 functional keys
| Item | Bank Atm Keypad |
| Input Voltage | 3.3V/5V |
| Waterproof Grade | IP65 |
| Actuation Force | 250g/2.45N(Pressure point) |
| Rubber Life | More than 500 thousand cycles |
| Key Travel Distance | 0.45mm |
| Working Temperature | -25℃～+65℃ |
| Storage Temperature | -40℃～+85℃ |
| Relative Humidity | 30%-95% |
| Atmospheric Pressure | 60Kpa-106Kpa |
Mainly designed for fuel dispenser, kiosk, ticket terminals and so on.
