1.Key frame using engineer PC/ABS.
2.Buttons made of high quality 304# brushed stainless steel.
3.Conductive silicone rubber produced using natural rubber, wear resistance, corrosion resistance, anti-aging
4.Board uses double-sided PCB (customized), contacts Gold-finger use of gold process, the contact is more reliable
| Item | outdoor keypad |
| Input Voltage | 3.3V/5V |
| Waterproof Grade | IP65 |
| Vandal roof Grade | IK09 |
| Working Life | More than 1 million time per key |
| Key Elasticity | 250g/2.45N |
| Key Travel Distance | 0.45mm |
| Working Temperature | -25℃～+65℃ |
| Storgage Temperature | -40℃～+85℃ |
| Relative Humidity | 30%-95% |
The keypad is mainly used for access control system
Send Message
Related Products
Model NO. B802
