Model NO.
B721
Quantity:

1.Keypad made of stainless steel.Vandal resistance.
2.Font button surface and pattern can be customized according to customer requirements
3.Double-sided board,Good for contact of gold-finger.
4.3X4 layout, Matrix design. 10 number buttons and 2 function buttons





ItemVending Machine Key Pad
Input Voltage3.3V/5V
Waterproof GradeIP65
Actuation Force250g/2.45N(Pressure point)
Rubber LifeMore than 500 thousand cycles
Key Travel Distance0.45mm
Working Temperature-25℃~+65℃
Storage Temperature-40℃~+85℃
Relative Humidity30%-95%
Atmospheric Pressure60Kpa-106Kpa





Customized keypad







The keypad mainly used in access control system and kiosk
