1.Keypad made of stainless steel.
2.Vandal resistance and waterproof.
3.Font button surface and pattern can be customized according to customer requirements.
4.Buttons layout could be customized.
5.With the exception of the telephone, the keyboard can also be designed for other purposes.
| Item | Garage Door Keypad |
| Input Voltage | 3.3V/5V |
| Waterproof Grade | IP65 |
| Actuation Force | 250g/2.45N(Pressure point) |
| Rubber Life | More than 500 thousand cycles |
| Key Travel Distance | 0.45mm |
| Working Temperature | -25℃～+65℃ |
| Storage Temperature | -40℃～+85℃ |
| Relative Humidity | 30%-95% |
| Atmospheric Pressure | 60Kpa-106Kpa |
